Quick Details

  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: TIANMAI
  • Model Number: 20*15/20*10/30*20
  • Color: black as your requirement




Top Quality Made in China PVC or Rubber Water Stop




Quick Details

Type:
Other Waterproofing Materials,Other Waterproofing Materials,waterstop
Place of Origin:
SHN,SHN,Shandong China (Mainland) China (Mainland)
Brand Name:OEM
Model Number:KW-250Width:300mm-1800mmMaterail:PVC EVA and so on
Color:Black blue or as your requirement





Packaging & Delivery

Packaging Detail:as your requirement
Delivery Detail:15 days after receiving your deposit





Specifications

Infrastructure projects, tunnel, culvert, drainage works, and other structural joints of waterproof seal

A waterstop is an element of a concrete structure, intended to prevent the passages of fluids (such as water) when embedded in and running continuously through concrete joints. Waterstops are frequently manufactured from extruded plastics such as flexible polyvinyl chloride PVC, polyethylene (PE) orthermoplastic vulcanizate rubber (TPV); formed metal such as stainless steel, copper, or carbon steel; or extruded thermosets such as natural rubber,styrene-butadiene rubber, or neoprene rubb







Characteristics:

The waterstop belt can tight the airproofing, prevent making water, water penetration, shock absorption and cushion, for the characteristic of high flexibility and compression deformation.

There have to be some construction slot, sedimentation slot, transmutation slot for some reason of can not keeping affuse, or the transmutation of geology, or the thermal expansion and thermal contraction of the concrete for the reason of temperature, so it must to fix the waterstop belt to prevent leakage







Appications:

The product apply to the varies type concrete structure. Such as the underground projects of the retaining dam, reservoir, metro, culvert, tunnel lamp. In those projects, it can be prevent from that the groundwater (or out of bounds water) spill over into the buildings structure and also can prevent the buildings water leakage to the outside world.







Technology index:



number

item

index

B

S

J

1

Rigidity, HA

60±5

60±5

60±5

2

Tensile strength ,MPa ≥

15

12

10

3

Snap and elongation,%≥

380

380

300

4

transmutation

70×24h,% ≤

35

35

35

23×168h,% ≤

20

20

20

5

Tear strength21,KN/m ≥

30

25

25

6

Brittleness temperature, ≤

-45

-40

-40

7

Air aging31

70×168h

Rigidity, HA ≤

8

8

--

Tensile strength,MPa ≥

12

10

Snap and elongation,% ≥

300

300

100×168h

Rigidity, HA ≤

--

--

8

Tensile strength,MPa ≥

9

Snap and elongation,% ≥

250

8

Ozone ageing 50pphm: 20%, 48h

2grade

2 grade

0 grade

9

Rubber and metal bonding

In vivo sections flexibility

remark

1 rubber and metal bonded items apply only to the edge of waterstop which include steel.

2 demand and supply can discuss about the question if there is other special needs, such as mold assessment test, but the anti-mildew properties should be equal or higher than two grade.





Product show:







Top Quality Made in China PVC or Rubber Water Stop

Top Quality Made in China PVC or Rubber Water Stop

Top Quality Made in China PVC or Rubber Water Stop

Top Quality Made in China PVC or Rubber Water Stop

Top Quality Made in China PVC or Rubber Water Stop
